Upgrade Your Home Heating with the Viessmann Vitodens 200-W 199,000 BTU Condensing Boiler
Bring high-efficiency heating and smart control to your home with a compact wall-mounted design. The Viessmann Vitodens 200-W B2HE-199 (7722781) is a 199,000 BTU gas-fired condensing boiler designed to deliver reliable hydronic heating while using less energy than conventional boilers. Its stainless steel Inox-Radial heat exchanger, modulating MatriX-Plus burner, and intelligent Lambda Pro combustion control work together for efficient, clean operation. With integrated WiFi, a 7-inch touchscreen, and flexible system controls, it's a powerful heating solution that's built for comfort and long-term performance.
Key Features
High-Efficiency Condensing Performance
The Vitodens 200-W reaches up to 95% AFUE by capturing additional heat through condensation, helping reduce energy waste and operating costs while delivering dependable home heating.
Intelligent Combustion Control
The modulating MatriX-Plus burner and Lambda Pro combustion management automatically adjust operation to maintain efficient, clean combustion as gas type and quality change.
Compact Wall-Mounted Design
The space-saving 17-3/4-inch-wide cabinet mounts on the wall to free up valuable floor space. Its compact design makes it a practical choice for mechanical rooms where space is limited.
Smart, Convenient Controls
The integrated 7-inch color touchscreen and built-in WiFi make it easy to monitor and manage the heating system. Outdoor reset and multi-circuit controls provide additional flexibility for maintaining comfortable temperatures.
Product Details
- 199,000 BTU maximum input delivers powerful heating for larger homes.
- 95% AFUE helps improve energy efficiency and reduce wasted fuel.
- Wide 14-199 MBH input range helps match boiler output to changing heating demand.
- Stainless steel Inox-Radial heat exchanger provides durable, efficient heat transfer.
- MatriX-Plus burner delivers clean, quiet combustion.
- Lambda Pro automatically adjusts combustion for consistent performance.
- Integrated variable-speed pump helps optimize system operation.
- Built-in WiFi enables convenient remote system monitoring and control.
- Can connect to an indirect tank for domestic hot water production.
- Limited lifetime warranty.
Viessmann is a global leader in high-efficiency heating systems, known for durable engineering, advanced condensing technology, and long-lasting hydronic boiler solutions.
Additional Information
- Brand: Viessmann
- MPN: 7722781
- Series: Vitodens 200-W B2HE-199
- Product Type: Wall-mounted gas-fired condensing boiler
- Fuel Type: Natural gas or liquid propane gas
- Heating Input: 14-199 MBH
- Maximum Heating Output: 187 MBH
- AFUE: 95%
- Heat Exchanger: Stainless steel Inox-Radial
- Dimensions: 17-3/4" W x 21-3/4" D x 39" H
- Weight: 179 lbs.
- Boiler Supply/Return Connections: 1" male NPT
- Gas Connection: 3/4" NPT
- Electrical: 120V, 60 Hz
- Maximum Operating Pressure: 60 PSI
- Venting: Direct-vent or room-air dependent; multiple venting configurations available
Vitodens 200-W FAQ
What size home is the Viessmann Vitodens 200-W B2HE-199 designed for?
The B2HE-199 is designed for larger residential heating applications requiring up to 199,000 BTU of input. The correct boiler size should be determined by a heating load calculation rather than square footage alone.
How efficient is the Vitodens 200-W B2HE-199?
The B2HE-199 has a 95% AFUE rating and can reach up to 98% efficiency at full modulation under certain operating conditions. Its condensing design recovers additional heat from the flue gases to improve overall heating efficiency.
Can this boiler provide domestic hot water?
Yes, the Vitodens 200-W B2HE-199 can provide domestic hot water when paired with a compatible indirect storage tank. This lets the boiler handle both space heating and domestic hot water production within the same hydronic system.
What makes a condensing boiler different from a standard boiler?
A condensing boiler captures additional heat from water vapor in the exhaust gases instead of allowing that heat to escape through the vent. This allows the Vitodens 200-W to achieve higher efficiency than conventional non-condensing boilers when operating conditions allow for condensation.
Can the Vitodens 200-W be controlled remotely?
Yes, the B2HE-199 has built-in WiFi and a 7-inch color touchscreen control for convenient system management. Its integrated controls also support outdoor reset operation and multiple heating circuits.
If you have any questions before purchasing, contact the Plumbing Deals via the live chat feature, email at contact@plumbingdeals.com, or give us a call at 888-682-5956!
| Weight | 179.0 lb |
|---|---|
| Collection | Vitodens 200-W |
| Fuel Type | Natural Gas |
| Height | 39.00 in. |
| Horse Power | 1/3 |
| Installation Type | Wall Mount |
| Length | 21.75 in. |
| Vent Type | Direct |
| Voltage | 120V |
| Width | 17.75 in. |
| Inventory Number | VIESB2HE199 |
| MPN | 7722781 |
| BTU | 199,000 |
