With their self-lubricating design and no mechanical seal, Taco 00 Series Cartridge Circulators provide unmatched reliability that makes them maintenance free. Every Taco 00 Series Cartridge Circulator and 00 IFCm  circulator features a field-replaceable cartridge that contains all the moving parts. Replacing the cartridge rebuilds the circulator, so field service is fast and simple. 00 Series Cartridge Circulators wide variety of configurations, flange orientation, mounting and other options, materials and capabilities provide you with great performance in a broad range of applications. Taco 00 IFC Cartridge Circulators feature an Integral Flow Check (IFC) that eliminates the additional installation costs that go along with separate in-line flow checks, improves system performance and further reduces maintenance.

• Motor Voltage: 115V
• Max Flow: 28 GPM
• Max Head: 30'
• Max Operating Temp: 230 Degrees
• Max Operating Pressure: 125 PSI
• Connection Sizes: 3/4", 1", 1-1/4", 1-1/2 Flanged
• Exclusive Anti-Condensate Baffle with Ambient Air Flow to protect motor windings against condensate buildup
• High Velocity Performance-Compact Design
• Replaceable Cartidge Design
• Universal flange to flange dimensions
• Self lubricating and no mechanical seal means this pump is maintenance free
• Stainless Steel Construction

Weight	11.0 lb
Height	6.50 in.
Horse Power	1/3
Length	7.50 in.
Room	Utility
Voltage	115V
Width	7.50 in.
Inventory Number	TAC011SF4
MPN	0011-SF4
