The Legend Valve 461-283 is a 3/4" x 3/4" x 1/2" two-port open multi-port tee designed for use in PEX plumbing systems. Constructed from durable PPSU (polyphenylsulfone), this fitting is intended for cold and hot potable water distribution, offering a high-strength, corrosion-resistant alternative to metallic fittings. It features cold expansion barbed end connections compatible with PEX tubing conforming to ASTM F1960 standards. This tee is suitable for residential and commercial applications, providing reliable performance in various plumbing installations.

• An ideal high-strength corrosion-free alternative to metallic fittings
• Configuration: 3/4" x 3/4" x 1/2" open multi-port tee
• Material: PPSU (polyphenylsulfone)
• Connection Type: Cold expansion PEX (ASTM F1960)
• Pressure Rating: 100 psi
• Temperature Rating: 180 degrees F

Weight	0.5 lb
Height	1.55 in.
Length	7.00 in.
Material	Polyphenylsulfone
Sub Type	Compression Fittings
Type	Brass Fittings
Width	2.70 in.
Inventory Number	UPOPL34X12X2MANT
MPN	461-283

• Specification Sheet
