Press-type end connections eliminate the need for soldering, reducing labor and material costs and eliminating the fire hazard associated with the process. Press-to-connect connections are designed for installation onto ASTM B88 types K, L and M hard-drawn copper tubing. Coiled (annealed) soft copper tubing is not recommended but can be used if the ends are made round. Feature molded recess O-rings which, when un-pressed, create leak-path at multiple points during the pressure test to identify an un-pressed joint quickly.

• Size: 1"
• Connection: Press x PEX (F1960)
• Material: No-lead DZR forged brass
• Design: Straight adapter for system transitions

Weight	0.5 lb
Height	1.30 in.
Length	2.50 in.
Material	Brass
Sub Type	PEX Press Fittings
Type	PEX Fittings
Width	1.50 in.
Inventory Number	LEG450865P
MPN	450-865P
