Specifications

• Voltage: 30 mV
• Connection Type:Push-in Clip
• Connection Type: 11/32 32 Male Connector Nut
• Lead Length (in.): 24 in.
• Lead Length: (mm) 457
• Open Circuit Output (mV): 26 mV to 32 mV
• Resistance: 0.02 ohm
• Temperature Ratings (F): Hot Junction 1400 F
• Temperature Ratings (F): Cold Junction 780
• Includes: Adapter and Push In Clip

Features

• Push-in clip, split nut, and adapter assembly for easy pilot burner installation.
• Spade or quick-connect terminals available for millivolt gas control connections.

Weight	0.99 lb
Height	6.00 in.
Length	6.00 in.
Width	6.00 in.
Inventory Number	HONQ340A1074
MPN	Q340A1074
