Features

• Push-in clip, split nut, and adapter assembly for easy pilot burner installation.
• Spade or quick-connect terminals available for millivolt gas control connections.

Specifications

• Voltage: 30 mV
• Connection Type: Push-in Clip
• Connection Type: 11/32 32 Male Connector Nut
• Lead Length (in.): 18 in.
• Open Circuit Output (mV): 26 mV to 32 mV
• Resistance: 0.02 ohm
• Temperature Ratings (F): Hot Junction 1400 F
• Temperature Ratings (F): Cold Junction 780
• Includes: Adapter and Push In Clip

Weight	0.4 lb
Color	Silver Tones
Height	4.53 in.
Length	0.75 in.
Material	HAWA
Width	4.53 in.
Inventory Number	HONQ340A1066
MPN	Q340A1066
