Features

• Point-of-use heating eliminates long hot water pipe runs
• Compact design - fits virtually anywhere
• Hot or cold water feed
• Adjustable temperature control 50-140 degrees F
• T&P valve included
• Single weld glass lined tank for extended life
• Floor mount or wall hung (bracket included)
• Status indicator light
• 120V cord provided for EMT1, EMT2.5, EMT 4
• EMT6 must be hardwired
• ETL listed to UL174 and NSF372

Applications

• Shopping mall and Retail outlets
• Schools and all other public buildings
• Office and tenant spaces
• Commercial builds such as Restaurants and Service Stations
• Modular buildings, office and trailers
• Concession stands and food service locations
• Any remote sink that does not have hot water

Installation

• Sizing - Size based on performance and not electrical infrastructure. Three key factors, incoming water temperature, water volume, and desired outlet temperature.
• Electrical - All Eemax Mini Tanks are designed to be plugged into a 110 Volt outlet, except for the EMT6 which needs to be hardwired.
• Plumbing - Pre-heated or Cold water feed . This family of Eemax products has thermostatic control and is capable of reacting to changing temperatures while providing stable output.
• Local Codes - Please check all applicable codes, national and local to ensure compliance both on the plumbing and electrical installation
• Mounting - This family of Eemax products are to be mounted vertically with the water connections on the top. Inlet is on the right, outlet is on the left. This can not be reversed

More Info

• Spec Sheet
• Owner's Manual
• BIM
• Warranty

Weight	15.5 lb
Height	18.00 in.
Length	16.00 in.
Width	10.00 in.
Inventory Number	EEMEMT25
MPN	EMT2.5
